Intergration |
Frequency Range |
400-470MHz |
Channel Spacing |
Digital : 12.5KHz , Analogue : 12.5/25KHz |
Channel Number |
1024 |
Standard Package |
1700mAh , Lithium-ion |
Working Temperature |
-20℃~+50℃ |
Storage Temperature |
-40℃~+80℃ |
Working Voltage |
7.2VDC |
Working Currency |
< 1300mA |
Weight |
248 g |
Size |
61 x 32 x 120 (mm) |
|
Receiver |
Frequency Stability |
±2.5ppm |
Inter-modulation |
65dB |
Co-channel Rejection |
-8dB@12.5KHz |
Spurious Inhibition |
-57dBm@<1GHz , -47dBm@>1GHz |
Block |
84dB |
Adjacent Channel Selectivity |
60dB@12.5KHz |
Spurious Response |
≥70dB |
Regulated Audio Power |
1W |
Digital Sensitivity |
0.3µV / -117.4dBm(BER 5%) , 0.7µV / -110dBm(BER 1%) |
|
|
|
Transmitter |
Transmission Power |
≤5W |
FM Noise |
40dB@12.5KHz |
Transmission Spurious |
-36dBm@<1GHz , -30dBm@>1GHz |
Adjacent Power |
-60dB@12.5KHz |
Bandwidth Limit |
2.5KHz@12.5KHz |
Spare Time Slot Power |
-57dBm |
Modulation Characteristics |
+1dB~-3dB |
Digital Transmission
Bit Error Rate |
≤3% |
Output Power |
≤5W |
4FSK Digital
Modulation Method |
12.5KHz(data only):7K60FXD
12.5KHz(data+voice):7K60FXE |
|
|
|
